Servo Digital Micro Metal Gear FS90MG

Servo Digital Micro Metal Gear.

Spesifikasi:

• Model: FS90MG
• Operating Voltage Range: 4.8 ~ 6V
• Running Degree: 180° (500 ~ 2500 usec)
• Rotating Direction: CW (1500 ~ 900 usec), CCW (1500 ~ 2100 usec)
• Gear Type: Copper
• Limit Angle: 180 Degree
• Bearing: No Ball Bearings
• Horn Gear Spline: 21T
• Horn Type: Plastic, POM
• Case: ABS
• Connector Wire: 250mm
• Motor: Metal Brush Motor
• Idle Current: 5mA ~ 6mA
• No Load Speed: 0.07sec/60degr@6V
• Running Current (No Load): 220mA@6V
• Peak Stall Torque: 2.2kg.cm@6V
• Rated Torque: 0.7kg.cm@6V
• Stall Current: 800mA@6V
• Storage Temperature Range: -30°C ~ +80°C
• Operating Temperature Range: -1°C ~ 70°C

Dokumen:

1. Datasheet (Link)
